AF
Ceiling Extractor Fan
Features
Detachable grill for easy cleaning.
Longer cowl for easy installation in an insulated ceiling of a small public area
Motors
Ball bearing motor ensure low noise.
Maintenance free for life
Dimensions
Model
A
Bø
C
Dø
E
Fø
G
H
I
AF20A
280
4.5
264
200
30
212
248
4
290
AF25A
354
4.5
332
250
30
264
310
4
365
Technical Data
Model
V
Hz
W
A
m
3
/hr
dB
AF20A
220
50
24
0.09
550
47
AF25A
220
50
32
0.15
900
49
Wiring
