Condensor Fans
|
 |
  |
Features
- The CF Condensor fans have a tough epoxy paint finish for adequate protection against corrosion while the rigid wire formed welded frame is electroplated prior to epoxy paint.
- All models also include a steel finger proof guard ISO13582.
- The fans are highly sufficient for moving high volumes of air at relatively low pressures.
|
Motors
- The motors are protected to Ip54 with Class F insulation, being highly resistant to dust and water ingress and features sealed for life bearings.
|
| |
|
  |
Dimensions
|
| Model |
A∅ |
B∅ |
C∅ |
D |
E |
F |
G |
H |
J |
K |
Kg |
| 350 |
350 |
370 |
102 |
30 |
1074 |
30 |
80 |
9.5 |
422 |
5 |
4.9 |
| 400 |
400 |
420 |
102 |
30 |
117 |
30 |
90 |
9.5 |
470 |
5 |
7.2 |
| 450 |
450 |
470 |
102 |
30 |
130 |
30 |
90 |
9.5 |
522 |
6 |
7.2 |
| 500 |
500 |
520 |
137 |
30 |
129 |
30 |
90 |
10.5 |
570 |
6 |
9.5 |
| 630 |
630 |
650 |
137 |
30 |
164 |
30 |
100 |
10 |
750 |
7.5 |
15 |
|
| |
  |
| |
| |
m3s@Pa |
|
|
FLS |
SC |
Input |
dB(A) |
|
| Model |
0 |
25 |
50 |
75 |
100 |
125 |
150 |
175 |
200 |
V |
r/min |
Amps |
Amps |
Power W |
@3m |
Kg |
| 315/4-1 |
0.423 |
0.370 |
0.203 |
0.162 |
0.128 |
0.088 |
0.016 |
|
|
220/1/50 |
1370 |
0.35 |
1.10 |
80 |
49 |
3.3 |
| 350/4-1 |
0.726 |
0.672 |
0.582 |
0.437 |
0.322 |
0.240 |
0.169 |
0.096 |
|
240/1/50 |
1400 |
0.7 |
2.1 |
150 |
53 |
4.9 |
| 350/43 |
0.716 |
0.662 |
0.574 |
0.431 |
0.317 |
0.237 |
0.167 |
0.095 |
|
400/3/50 |
1380 |
0.38 |
1.1 |
140 |
53 |
4.9 |
| 400/4-1 |
1.083 |
0.983 |
0.874 |
0.613 |
0.435 |
0.311 |
0.124 |
|
|
240/1/50 |
1380 |
0.82 |
2.5 |
180 |
59 |
7.2 |
| 400/4-3 |
1.083 |
0.983 |
0.874 |
0.613 |
0.435 |
0.311 |
0.124 |
|
|
400/3/50 |
138 |
0.47 |
1.6 |
180 |
59 |
7.2 |
| 450/4-1 |
1.365 |
1.245 |
1.134 |
0.971 |
0.641 |
0.417 |
0.182 |
|
|
240/1/50 |
1350 |
1.1 |
3.3 |
250 |
59 |
7.2 |
| 450/4-3 |
1.375 |
1.254 |
1.142 |
0.978 |
0.646 |
0.420 |
0.183 |
|
|
400/3/50 |
1360 |
0.6 |
1.84 |
250 |
59 |
7.2 |
| 500/4-1 |
1.871 |
1.767 |
1.648 |
1.497 |
1.278 |
0.979 |
0.761 |
0.588 |
|
240/1/50 |
1370 |
1.55 |
4.7 |
350 |
63 |
9.5 |
| 500/4-3 |
1.803 |
1.703 |
1.588 |
1.442 |
1.231 |
0.943 |
0.733 |
0.567 |
|
400/3/50 |
1320 |
0.9 |
2.65 |
350 |
31 |
9.5 |
| 630/4-3 |
0.000 |
0.000 |
0.000 |
0.000 |
0.000 |
0.000 |
0.000 |
|
|
400/3/50 |
1370 |
1.45 |
2.8 |
770 |
78 |
15 |
| 630/6-3 |
2.916 |
2.651 |
1.949 |
1.949 |
1.512 |
1.140 |
0.828 |
0.530 |
|
400/3/50 |
900 |
1.56 |
4.7 |
600 |
66 |
15 |
|
| |
 |
|
